Well, I'm still being bitten by the modern car bug, so here's my next one that'll take me into '07........Revell's '05 Corvette.

This model should be very simple to do due to Revell’s easy (at most times) assembly. The color I picked is one of my favorite GM colors…………….It’s Sunset Orange, that’ll have a simulated glass roof since Revell didn’t seem fit to replicate this in scale.
Here’s a pic of a car similar to what I’ll be doing…….

Posted Image
Posted Image

These are eBay pics so I could get some reference……….this car has been modified somewhat in the engine department, but I’ll be building mine bone stock. The interior I may do in a beige color, but I’ll have to see as I get closer to building it up.

The first thing I did was getting rid of the mold lines and block sanding the body to get everything nice and straight. A Ted “Chopper” Lear trick I used to keep mold lines (and scripts and whatnot) from reappearing is to sand away the mold lines per normal……….then take some liquid glue and brush over the area. My choice of liquid glue is Ambroid Pro Weld.

After the area has dried for awhile, you’ll notice that the mold line magically reappears! Not to worry, simply sand the area away again, and you’ll get rid of the mold line forever.

See, the trick is getting the solvents to soften the plastic because the plastic once molded, has a “memory”. Once the area is softened up, the molded area will show up what was molded there, be it scripts or trim or whatever. You’re getting rid of the “memory” by sanding it away because of the hot solvents in the glue…………….which since paint is not as hot as glue itself, the mold lines shouldn't reappear once painted.

Thanks Ted! 8)

One of the things I noticed in this model is how “soft” the body appears. I don’t know if it’s because of the new plastic or what. I wanted to sharpen up the fender creases somewhat so here’s what I did…………..I laid a piece of tape across the peak of the fender and then with a balsa sanding block and 400 grit sandpaper, sanded away lengthwise along the tape.

Posted Image
Posted Image

This was repeated for the other fenders as well………….it’s something that’s not noticeable to most but something that I wanted to do for myself. :)

Hmmm…………lets open the grille for grins………:) I got out the dremel-moto tool and started to slowly grind away at the inside of the grille. One has to work slowly here, as a slip up can ruin your day!

Posted Image

As one can see here you have to work slooooooowllllllly! You’ll start to see the grille bars showing from the other side.

Posted Image

After I was satisfied from grinding out the plastic with the dremel, I used a riffler file to grind out the rest of what was needed.

Posted Image

Ahhhhh, now this looks so much better! I have to admit that this was my first try at something like this! I’ll take an exacto blade and clean things up a bit around the edges.

Posted Image
Posted Image

I got curious and started fitting the chassis and interior inside the body, and I noticed that peculiar wheel placement that I heard others complaining about in the past.

This’ll have to be taken care of before too much chassis work is done……….if you notice that the opening of the brake discs are not quite centered in the wheelwell. I’ll have to figure a way around this one without it looking too gimmicky.

Posted Image

Okay, that’s it for now………the next step is to clean up the paint booth (still dusty from the Mustang! :)) and spray on several coats of Future Floor Wax, to get ready for primer!

Stay tuned! :wink:





#2 ismaelg

ismaelg

    MCM Ohana

  • Members
  • PipPipPipPipPipPip
  • 2,047 posts
  • Location:Puerto Rico

Posted 23 December 2006 - 06:33 AM

Looking good Bill! I'm out of town but I'll write a longer note later. This is one of my all time favorite kits. Watch out for the soft plastic. Plastikote, VX and Moon Mud primers work fine. I had problems with Duplicolor. Also watch out for the front driver's side wheel alignment. I also found out that it is easier to install the headlights separated. I cut them into 3 individual parts.
I've built 3 but I have the itch to do another one, this time Atomic Orange with tan/black interiors.
Looking forward to see yours built!!!

Thanks,

#3 MrObsessive

MrObsessive

    MCM Ohana

  • Members
  • PipPipPipPipPipPip
  • 4,811 posts
  • Location:Steelton, PA

Posted 23 December 2006 - 07:55 AM

Looking good Bill! I'm out of town but I'll write a longer note later. This is one of my all time favorite kits. Watch out for the soft plastic. Plastikote, VX and Moon Mud primers work fine. I had problems with Duplicolor. Also watch out for the front driver's side wheel alignment. I also found out that it is easier to install the headlights separated. I cut them into 3 individual parts.
I've built 3 but I have the itch to do another one, this time Atomic Orange with tan/black interiors.
Looking forward to see yours built!!!

Thanks,


Thanks for the heads up Ismael!

Like the Mustang I'm gonna use the Future for some extra insurance.........and then it'll get primered with Rustoleum sandable primer. I've had pretty good success with that so far as far as compatiblity with the automotive paints I like to use.

I have Sunset Orange paint mixed so far in a spray can by the local paint jobber.................I'll load it into an airbrush jar and spray away later.

As far as the headlights go, I was thinking of using several different sized MV lenses (?).............we'll see as I get closer to that step.


#4 93Z34

93Z34

    MCM Avid Poster

  • Members
  • PipPipPipPipPip
  • 309 posts
  • Location:North of Albany, NY
  • Full Name:Brian Batease

Posted 23 December 2006 - 12:22 PM

This car looks great so far Bill! I love the newer 'Vettes and I can't wait to see this one come together! You don't see many of these cars painted this color so yours will be a refreshing take on a great subject!!! You also did a great job with the grille work and it will really add to the overall appearance when the car is done! Keep us updated Buddy!!!! :) :) :)

#5 Billy Kingsley

Billy Kingsley

    MCM Ohana

  • Members
  • PipPipPipPipPipPip
  • 935 posts
  • Location:Hudson Valley NY
  • Full Name:Billy

Posted 23 December 2006 - 12:45 PM

I did the same thing as Chopper and was told I was nuts...Although I've only done it to remove copywright info on the bottom of NASCAR Chassis.

My solution was to stop telling people that's what I did, rather then listen to being told I was wrong.

Boy, that's vindication if you two guys do it :)

I'm not a real big fan of the new Corvette, but I do like it better in scale then in 1:1 (odd, isn't I? :) )

Are you going all out? You could put it next to your red Corvette with the working everything at shows.

#6 MrObsessive

MrObsessive

    MCM Ohana

  • Members
  • PipPipPipPipPipPip
  • 4,811 posts
  • Location:Steelton, PA

Posted 23 December 2006 - 01:42 PM

I'm afraid not Billy...........I'm at a point where I won't be doing near as much full detail stuff just simply to get more models done.

The exception may be the Z06 when I get around to it.......and of course the stillborn '55 Ford.

I've been superdetailing stuff for 10-15 years now and it's time for a needed change. :wink:


#7 MrObsessive

MrObsessive

    MCM Ohana

  • Members
  • PipPipPipPipPipPip
  • 4,811 posts
  • Location:Steelton, PA

Posted 23 December 2006 - 02:00 PM

I got nosy and did some investigative work with dial calipers to see just how off the driver’s side wheel placement is as Ismael had mentioned. As the above pic has shown, I thought it was the passenger side wheel that was off. Much to my surprise this it what I came up with……….

I tightened up the dial calipers when I first got a measurement on the passenger side…………

Posted Image
Posted Image

Note how the wheel would be about .10” rearward than the other side!……….this is the drivers side we’re looking at.

In the pic above, on the passenger side, I have the caliper right against the brake disc “shim”. How Revell got this measurement off is anyone’s guess……….but I have a way to fix it in due time. :wink:

I figured while I have the ambition……….might as well wash the body and all body related parts up really well, and then let air dry and spray on the Future.

Posted Image
Posted Image

Forgive the yellowish look of the body…………….My camera seems to have had indigestion at the moments I took these pics, although it’s probably the yellow halogen light I use when painting. :)

I’ll let this sit overnight, and then maybe if I don’t get too busy with all the hustle and bustle of Christmas Eve, I’ll primer it.

Thanks for lookin’!
