my take on the Revell '32 5-Window-Just a 426 Street Hemi


  • You cannot reply to this topic
39 replies to this topic

#1 Nick Winter

Nick Winter

    MCM Ohana

  • Members
  • PipPipPipPipPipPip
  • 4,926 posts
  • Location:Whitby,Ontario, Canada
  • Full Name:Nicholas J. Winter

Posted 05 May 2011 - 02:17 PM

What this is going in is a secret for now.

Parts by Parks Pre-wired Distributer + Coil

Smallblockdodge resins M/T valve covers

Parts box everything else.

Posted Image
Posted Image
Posted Image
Posted Image
Posted Image
Posted Image
Posted Image
Posted Image
Posted Image
Posted Image

let me know what you think.

Nick

Edited by Nick Winter, 16 May 2011 - 09:45 AM.


#2 my80malibu

my80malibu

    MCM Ohana

  • Members
  • PipPipPipPipPipPip
  • 1,709 posts
  • Location:Gilbert Arizona
  • Full Name:Gabriel Soto

Posted 05 May 2011 - 02:47 PM

Nick Engine detailing is one of my favorite things to do when modeling.I would like to give you a couple of suggestions.first shorten the spark plug boot material on the lead you have going to the coil.second, the holes you have drilled out of the valve covers are a little too large. I mean you only have to slip the plug wire into the hole.If thats what you are planning? Hemis usually require a large round spark plug boot. I usually punch out some thin small disk's out of the rubber material that I get from Photo etched pieces that do not use a "fret" (nothing goes to waste here). However Replicas in Miniature of maryland does offer some very cool looking resin spark plug boot's for the Hemi.



Thanks for posting and keep up the good work.

#3 Nick Winter

Nick Winter

    MCM Ohana

  • Members
  • PipPipPipPipPipPip
  • 4,926 posts
  • Location:Whitby,Ontario, Canada
  • Full Name:Nicholas J. Winter

Posted 05 May 2011 - 02:58 PM

Nick Engine detailing is one of my favorite things to do when modeling.I would like to give you a couple of suggestions.first shorten the spark plug boot material on the lead you have going to the coil.second, the holes you have drilled out of the valve covers are a little too large. I mean you only have to slip the plug wire into the hole.If thats what you are planning? Hemis usually require a large round spark plug boot. I usually punch out some thin small disk's out of the rubber material that I get from Photo etched pieces that do not use a "fret" (nothing goes to waste here). However Replicas in Miniature of maryland does offer some very cool looking resin spark plug boot's for the Hemi.



Thanks for posting and keep up the good work.

I plan to shorten the Lead that was a mock up for the photo, I do have apropriate sized boots for the Valve covers, but I'd love for you to sow how you do yours, they might be better then what I have.

Nick

#4 Dragline

Dragline

    MCM Ohana

  • Members
  • PipPipPipPipPipPip
  • 1,847 posts
  • Location:Baltimore by way of New Bedford Mass
  • Full Name:Bob Frias

Posted 05 May 2011 - 02:59 PM

You're stepping it up Nick.

I for one am pleased. It looks GREAT.


Bob

#5 diymirage

diymirage

    MCM Ohana

  • Members
  • PipPipPipPipPipPip
  • 3,507 posts
  • Location:michigan
  • Full Name:Eelco Egelmeer

Posted 05 May 2011 - 03:01 PM

looks like someones has got thier hands on a dodge dart kit

but this little hemi isnt going in a dart is it Nick?
its allright, you can tell us, what do you have planned for it ?
(im guessing something like a miata or an is2gay)

#6 ChrisPflug

ChrisPflug

    MCM Ohana

  • Members
  • PipPipPipPipPipPip
  • 640 posts
  • Location:Hawks, MI

Posted 05 May 2011 - 03:29 PM

It's an AMT Hemi- not one from the Revell Dart

And the cross ram says "race hemi rather than street"

I'd imagine it's going into something that wouldn't take it in the 1:1 world...

Edited by ChrisPflug, 06 May 2011 - 01:26 AM.


#7 highway

highway

    MCM Ohana

  • Members
  • PipPipPipPipPipPip
  • 4,373 posts
  • Location:Talentless Hack University at Wheelman's Warehouse
  • Full Name:Matthew Brownlee, card carrying member of the Donnie Boger fan club

Posted 05 May 2011 - 04:46 PM

It's an AMT Hemi- not one from the Revell Dart

Exactly Chris, it almost looks like one from a Coronet Pro Street kit, or at least it's stock counterpart. I've got me enough of those Pro Street kits to last a lifetime or two! :D ;)

#8 diymirage

diymirage

    MCM Ohana

  • Members
  • PipPipPipPipPipPip
  • 3,507 posts
  • Location:michigan
  • Full Name:Eelco Egelmeer

Posted 05 May 2011 - 09:23 PM

Exactly Chris, it almost looks like one from a Coronet Pro Street kit, or at least it's stock counterpart. I've got me enough of those Pro Street kits to last a lifetime or two! :lol: :lol:



go ahead and mail them to me then, i only have 3 :lol:


i just thought
it was the dart kit since the mani looked off

#9 Patrick2005

Patrick2005

    MCM Ohana

  • Members
  • PipPipPipPipPipPip
  • 520 posts
  • Location:Meadville, PA
  • Full Name:Patrick Myers

Posted 06 May 2011 - 02:13 AM

Gotta love a Hemi.......................whatever it's goin in!

#10 Foxer

Foxer

    MCM Ohana

  • Members
  • PipPipPipPipPipPip
  • 6,052 posts
  • Location:The Berkshires, Massachusetts
  • Full Name:Mike DeRagon

Posted 06 May 2011 - 02:29 AM

What did you use for chroming the valve covers? Whatever it was it looks really good. B)

And, a wild guess on the receiving body .. a GMC Truck! :lol:

#11 Nick Winter

Nick Winter

    MCM Ohana

  • Members
  • PipPipPipPipPipPip
  • 4,926 posts
  • Location:Whitby,Ontario, Canada
  • Full Name:Nicholas J. Winter

Posted 06 May 2011 - 11:55 AM

Dragline: thank you.
Eelco: Not from the Dart got it from a modeller in a trade some time ago. I'll address what in a minute.
Chris: your correct from what I was told it's an AMT, as for the race thing, I've seen the Cross-Rams in a few Street Machines and that's where I based my idea from.
Mike: I used Aluminum BMF, and no it's not going in a GMC

Big hint time: It's going in a FoMoCo vehicle, and the Vehicle will wear a set of 60's Halibrand Magnesium Wheels. B) Right now some are going "I know, I know!" other are going "What the heck kinda hint is that!"

Nick

#12 Nick Winter

Nick Winter

    MCM Ohana

  • Members
  • PipPipPipPipPipPip
  • 4,926 posts
  • Location:Whitby,Ontario, Canada
  • Full Name:Nicholas J. Winter

Posted 15 May 2011 - 12:57 PM

Back at it, had to wait for a PE set, and the kit it's going in, made my own plug boots, added PE Wire Looms.
Posted Image
Posted Image
Posted Image

Nick

#13 Nick Winter

Nick Winter

    MCM Ohana

  • Members
  • PipPipPipPipPipPip
  • 4,926 posts
  • Location:Whitby,Ontario, Canada
  • Full Name:Nicholas J. Winter

Posted 16 May 2011 - 09:49 AM

Since I got the car and have started it, It's no longer a secret.

PE grille test fit:
Posted Image
Posted Image

Should be done by Next May at my rate so far.

Nick

#14 Nick Winter

Nick Winter

    MCM Ohana

  • Members
  • PipPipPipPipPipPip
  • 4,926 posts
  • Location:Whitby,Ontario, Canada
  • Full Name:Nicholas J. Winter

Posted 25 August 2011 - 02:02 PM

Wow, forgot about this Project.

Posted Image
Posted Image
Posted Image
Posted Image

Still got a lot to do on my engine, and the rest of the Rod, the Hemi fits though!

Nick

#15 GTMust

GTMust

    MCM Ohana

  • Members
  • PipPipPipPipPipPip
  • 1,018 posts
  • Location:Belleville, Ontario, Canada
  • Full Name:Tony Durham

Posted 26 August 2011 - 03:05 AM

OK Nick..... I'm going to guess that you're going to put the engine in a '32 Ford 5 window........ did I guess right? (Perhaps I should have posted this guess before?????)

Keep it going.... I like it!

Tony

#16 crazyjim

crazyjim

    MCM Ohana

  • Members
  • PipPipPipPipPipPip
  • 11,850 posts
  • Location:Citrus Springs, FL

Posted 26 August 2011 - 06:46 AM

Looking good, Nick. What's the source of those carbs?

#17 Dr. Cranky

Dr. Cranky

    MCM Ohana

  • Members
  • PipPipPipPipPipPip
  • 15,421 posts
  • Location:Transylvania, Florida
  • Full Name:Virgil "Doctor Cranky" Suarez

Posted 26 August 2011 - 06:46 AM

Wow, great solid detailing so far. Please keep it going.

#18 Nick Winter

Nick Winter

    MCM Ohana

  • Members
  • PipPipPipPipPipPip
  • 4,926 posts
  • Location:Whitby,Ontario, Canada
  • Full Name:Nicholas J. Winter

Posted 26 August 2011 - 11:29 AM

Tony: That is correct Tony, better late then never as they say.
Jim: Thanks Jim, Pro Tech, they are cast metal, I just polished and detailed them.
Doc: Thanks Doc. I'll definatley be continueing on this project, got my motivation back on it.

Nick

#19 oldscool

oldscool

    MCM Ohana

  • Members
  • PipPipPipPipPipPip
  • 1,511 posts
  • Location:USA
  • Full Name:Gerald Goff

Posted 26 August 2011 - 01:49 PM

Nice engine! It will twist the frame in that Deuce ;)

gus

#20 Rob Z

Rob Z

    MCM Avid Poster

  • Members
  • PipPipPipPipPip
  • 471 posts
  • Location:Brunswick, Ohio
  • Full Name:Rob Zychowski

Posted 26 August 2011 - 05:18 PM

That's really gonna be a mover and a shaker... Looks great so far Nick, the engine detail is superb, I can't wait to see where this one is going... Gonna keep an eye on this one...
