How could I detail a battery?


  • You cannot reply to this topic
8 replies to this topic

#1 Mr. Moparman

Mr. Moparman

    MCM Ohana

  • Members
  • PipPipPipPipPipPip
  • 1,244 posts
  • Location:Taylorsville, Mississippi
  • Full Name:Brandon Henderson

Posted 05 September 2011 - 06:38 AM

I am working on my '70 Superbird, and was wondering what I could do to make the battery better. Thanks!

Edited by Mississippi Resins, 05 September 2011 - 06:38 AM.


#2 Foxer

Foxer

    MCM Ohana

  • Members
  • PipPipPipPipPipPip
  • 6,053 posts
  • Location:The Berkshires, Massachusetts
  • Full Name:Mike DeRagon

Posted 05 September 2011 - 07:03 AM

Just typical battery detailing here ... paint caps proper color, add PE cable ends and add decals representing the manufacture. Some corrosion would be appropriate also if it's a daily driver.

#3 crazyjim

crazyjim

    MCM Ohana

  • Members
  • PipPipPipPipPipPip
  • 11,850 posts
  • Location:Citrus Springs, FL

Posted 05 September 2011 - 07:41 AM

Add battery cables.

#4 pr8headed

pr8headed

    MCM Member

  • Members
  • PipPip
  • 12 posts
  • Location:Indiana
  • Full Name:Tim Bagshaw

Posted 05 September 2011 - 11:40 AM

I found this idea the other day hope it helps. http://modeltech.tripod.com/csbatt.htm

#5 Longbox55

Longbox55

    MCM Ohana

  • Members
  • PipPipPipPipPipPip
  • 1,643 posts
  • Location:Danville Il
  • Full Name:Bill Burmeister

Posted 05 September 2011 - 03:22 PM

When adding cables, do some research on the 1:1 on how they are routed, especially on where they connect. Generally, the Positive cable will go from the battery terminal to the starter solenoid (GM and most late models)or to the starter relay ('60-'80s Fords as well as '60s MoPars). The Negative will usually connect to the engine block, though sometimes they will attach to the accessory mounting brackets. Again, this will vary.
Also, you'll want to verify what BCI group battery a given vehicle takes, as the post configurations will vary by group size.
Another thing to keep in mind, especially if you're building pre-'56 vehicles with 6 volt batteries, many of them were also positive ground. They were hooked up reverse of what a modern 12 volt negative ground system is. Fords through '55 6 volt and the '56 Fords with 12 volt were this way, as were GMC 6 volt trucks through '57.
One more thing, don't assume that the Positive cable should be red and the Negative should be black. Most oem cables were black on both, and on many older vehicles, they used a braided strap for the ground instead of a cable. Even on late models, only the cover for the terminal end itself is color coded.

Edited by Longbox55, 05 September 2011 - 03:23 PM.


#6 W-409

W-409

    MCM Ohana

  • Members
  • PipPipPipPipPipPip
  • 5,629 posts
  • Location:Vantaa, Finland
  • Full Name:Niko Lindström

Posted 06 September 2011 - 04:36 AM

Well, I have used Detail Master's Battery Hardware set, that's great. I usually build the bracket from scratch, or then I use one from that hardware set. There's only one type of bracket on the set, so sometimes it needs to be scratchbuilt. Then of course painting the details, and photo etch cable clamps. It works fine, here is a picture of '70 Super Bee's battery which is detailed with that hardware set, and some scratchbuilt parts.

Posted Image

#7 MikeMc

MikeMc

    MCM Ohana

  • Members
  • PipPipPipPipPipPip
  • 4,577 posts

Posted 06 September 2011 - 05:35 AM

One thought...know what the correct battery is...IE...6v had 3 caps, 12v had 6 caps....I even have a few 5 cap batteries...never saw one of those in 1:1

#8 Steve Keck

Steve Keck

    MCM Avid Poster

  • Members
  • PipPipPipPipPip
  • 495 posts
  • Location:Northwest Phoenix - it's not always a dry heat
  • Full Name:A heavily Weathered Gentleman

Posted 06 September 2011 - 07:01 AM

.......on many older vehicles, they used a braided strap for the ground instead of a cable.


Electronic supply stores sell wicking used to suck up excess solder. It is braided copper and comes in various sizes - perfect for the ground strap.

#9 Scale-Master

Scale-Master

    MCM Ohana

  • Members
  • PipPipPipPipPipPip
  • 2,895 posts
  • Location:So. Cal. Beach area

Posted 11 September 2011 - 09:30 AM

Here's one I made a while back, (just stumbled on it by clicking he wrong button...), the labels really help a lot I think.

http://www.modelcars...hp?showtopic=94

Proper cable ends don't hurt either...
