Posted 24 December 2012 - 10:25 PM

I just got home from work and thought that I'd type out a quick post. I got a start on my side trim tonight at work. I had sprayed a quick coat of primer on the rear fins before work so I could check the look of them. They turned out pretty nice with only a couple of pinholes to fill and a couple spots of putty to sand down. I'll post some pics tomorrow (today actually) when I wake up.


Later-

#62 crazyrichard

crazyrichard

    MCM Ohana

  • Members
  • PipPipPipPipPipPip
  • 4,090 posts
  • Location:netherlands on styrene clogs
  • Full Name:richard gelens

Posted 25 December 2012 - 02:15 AM

awsome build vant woight to se ethe chop

#63 Modlbldr

Modlbldr

    MCM Ohana

  • Members
  • PipPipPipPipPipPip
  • 1,821 posts
  • Location:North of Spokane, WA
  • Full Name:Tom Kendall

Posted 25 December 2012 - 10:04 AM

As promised I have some photos to share.
I received my 50 Caddy rear bumper. What a nice piece.

I began cutting some of the width out of it and I had to grind out some of the back of it to get it to tuck up to the body.
This is where it sits now. I haven't gotten back to finishing it.

So, after sanding down the second coat of putty and a quick coat of primer I got to work on the side trim.
I added a small strip of styrene to extend the bottom piece of trim with the idea of making the trim to replicate the molded in trim. Then I came to my senses and I think I will be making a mold of the lower trim from a second body to replicate this. I think it will be the easier way to go. So I will be removing that small strip of styrene near the taillight.
Next I took a strip of .020 X .020 and glued it in place for the upper trim piece.
Now to get the driver's side to match.
That is all I got done on my breaks last night. At least I'm making forward progress. Once I get the trim on I think I will be finishing the door panels OR chopping the top. Stay tuned.

Later-

Edited by Modlbldr, 25 December 2012 - 10:07 AM.


#64 sbk

sbk

    MCM Friend

  • Members
  • PipPipPipPip
  • 142 posts
  • Location:Lafayette, LA
  • Full Name:Steve Boutte

Posted 25 December 2012 - 11:42 AM

Looking good! I see that you cut the upper fender parts off of the Caddy bumper, so, what's your plan?



#65 Modlbldr

Modlbldr

    MCM Ohana

  • Members
  • PipPipPipPipPipPip
  • 1,821 posts
  • Location:North of Spokane, WA
  • Full Name:Tom Kendall

Posted 25 December 2012 - 12:05 PM

sbk-
That was merely an accident. I thought that they were just extra resin from the mold. I cut them off before I realized they were supposed to be there. (Kicking myself now) I'll have to make new ones.
I'm really thinking strongly about ordering that 49 Caddy front grille and bumper from Modelhaus that you posted to use on my 51 Chevy Fleetline build.

Later-


#66 Art Anderson

Art Anderson

    MCM Ohana

  • Members
  • PipPipPipPipPipPip
  • 3,119 posts

Posted 25 December 2012 - 12:31 PM

I know I came in pretty late on this one (nice work, BTW!) but it might have been easier to have snared a JoHan/X-EL '56 Desoto for the rear quarters and the front valance, as Desoto used the same sheet metal in '56 as did Chrysler, with only minor differences in the grille opening, and of course different taillights and rear bumpers.



Just a thought.



Art



#67 Modlbldr

Modlbldr

    MCM Ohana

  • Members
  • PipPipPipPipPipPip
  • 1,821 posts
  • Location:North of Spokane, WA
  • Full Name:Tom Kendall

Posted 25 December 2012 - 01:57 PM

Art-

I'll keep that in mind because I have another one that I want to build in the future that Troy Trepanier did of a similar car. I think it was a New Yorker. It had the same grille as the 55 300. I think it was called the Rose Bird.


Later-

#68 kylexgore

kylexgore

    MCM Friend

  • Members
  • PipPipPipPip
  • 123 posts
  • Location:Southeast Texas
  • Full Name:Kyle

Posted 03 January 2013 - 03:26 PM

Everything looks good so far Tom!



#69 Modlbldr

Modlbldr

    MCM Ohana

  • Members
  • PipPipPipPipPipPip
  • 1,821 posts
  • Location:North of Spokane, WA
  • Full Name:Tom Kendall

Posted 03 January 2013 - 07:27 PM

Thanks. Still trying to muster up the energy after work to get back on this. Got to get the other side trim put on and the rear bumper squared away.

Later-

#70 Modlbldr

Modlbldr

    MCM Ohana

  • Members
  • PipPipPipPipPipPip
  • 1,821 posts
  • Location:North of Spokane, WA
  • Full Name:Tom Kendall

Posted 12 January 2013 - 12:34 AM

I'm sick this weekend and I'm gonna hang around the house, so look for some updates by Sunday night.

Later-

#71 Modlbldr

Modlbldr

    MCM Ohana

  • Members
  • PipPipPipPipPipPip
  • 1,821 posts
  • Location:North of Spokane, WA
  • Full Name:Tom Kendall

Posted 13 January 2013 - 09:55 PM

Well, I got some progress made one this one amongst sneezing and wiping my nose.
I got the driver's side chrome on to match the passenger side. It's not as pretty but it'll work. I did some more work on fitting the rear bumper but it is fighting me. I had to build up the lower part of the taillights and that is in the first stage. Gonna take quite a bit of work there. To help save my sanity I worked on something simple. I began constructing the interior door panels. First I removed all of the molding. Then, using the only two photos I have of the interior I made my best guess.
Here is one of the photos from the mag article.
Here is what I have so far.
After I primer and paint these I will add the chrome accents using thin wire.
Now that I look closer at it the top piece
should go all the way to the top of the door. The upper chrome accent is in the center of the light blue section. Should be an easy fix by making another piece ti glue above it and the chrime accent will go over the dividing line. I'll fix thar in the morning.
Once I get the rear bumper and fenders ironed out I'll shoot some photos of that.
Thanks for tuning in.

Later-

Edited by Modlbldr, 13 January 2013 - 10:01 PM.


#72 Modlbldr

Modlbldr

    MCM Ohana

  • Members
  • PipPipPipPipPipPip
  • 1,821 posts
  • Location:North of Spokane, WA
  • Full Name:Tom Kendall

Posted 13 January 2013 - 10:20 PM

This is the fix I was talking about.
The top of the door panel needed filled in. It took about a minute to do with scrap. Once the glue dries thoroughly I can trim and sand it to shape. Then I can put the wire on it after paint. Got to do the passenger door now.

Later-

Edited by Modlbldr, 13 January 2013 - 10:22 PM.


#73 Modelbuilder Mark

Modelbuilder Mark

    MCM Ohana

  • Members
  • PipPipPipPipPipPip
  • 1,263 posts
  • Location:Phoenix
  • Full Name:Mark Hubbard

Posted 14 January 2013 - 12:07 PM

Once done, you should consider having them cast.



#74 Modlbldr

Modlbldr

    MCM Ohana

  • Members
  • PipPipPipPipPipPip
  • 1,821 posts
  • Location:North of Spokane, WA
  • Full Name:Tom Kendall

Posted 05 February 2013 - 11:06 AM

Quick test of PhotoBucket. It hasn't been letting me upload photos for a few weeks.

Later-

#75 Modlbldr

Modlbldr

    MCM Ohana

  • Members
  • PipPipPipPipPipPip
  • 1,821 posts
  • Location:North of Spokane, WA
  • Full Name:Tom Kendall

Posted 05 February 2013 - 11:08 AM

WhooHooo!! It's working again!
Stand by for update.

Later-



#76 george 53

george 53

    MCM Ohana

  • Members
  • PipPipPipPipPipPip
  • 8,867 posts
  • Location:Allen Park, MI 48101
  • Full Name:George53

Posted 05 February 2013 - 11:30 AM

Nice dog. GREAT project!



#77 Modlbldr

Modlbldr

    MCM Ohana

  • Members
  • PipPipPipPipPipPip
  • 1,821 posts
  • Location:North of Spokane, WA
  • Full Name:Tom Kendall

Posted 05 February 2013 - 12:18 PM

Yeah, I wish it were mine. I saw it at the grocery store. It took up the entire rear seat of the Dodge crewcab.
Anywho- I have been plugging along on this and another project since not being able to upload pictures through PhotoBucket.
I got the door panels to the primer stage. Nothing exciting there. I added a styrene strip to the area behind the rear bumper to give the three pieces something to attach to. Fitting the rear bumper is proving to be a real chore. the wrap around portions don't fit the profile of the rear fenders so I had to make a relief cut on the bumper to tuck it in.Fits much better now.
I have done quite a bit of work shaping the lower rear fender and taillight areas and about have it down.

I got the driver's side trim on and havena bit of cleaning to do there.

I made some molds from black RTV of the molded in body chrome and now I need to mix up some 5 minute epoxy to make the chrome to extend on the rear fender extentions.

Lastly, I rounded the rear hood corners.

I've been looking for little things to do to avoid having to chop the top yet. I want that to be the last thing I do.

Now for a few photos of my newest project that I'm using as fill in.
Copying some ideas from this 1:1 for my 51 Fleetline.

Later-

#78 Duntov

Duntov

    MCM Ohana

  • Members
  • PipPipPipPipPipPip
  • 1,278 posts
  • Location:Atlanta
  • Full Name:Bill Lucianno

    "Mi sono perso"

Posted 07 February 2013 - 05:05 PM

Like you models but I really like the dog!!!!



My Elkhound (passed away)..... was always hanging around under the work bench......


Edited by Duntov, 07 February 2013 - 05:05 PM.


#79 Modlbldr

Modlbldr

    MCM Ohana

  • Members
  • PipPipPipPipPipPip
  • 1,821 posts
  • Location:North of Spokane, WA
  • Full Name:Tom Kendall

Posted 02 March 2013 - 06:20 PM

I spent most of the day at the dining room table with a buddy of mine working on our models, listening to music and shooting the breeze. I didn't get much done, but had a great time. I got the front bottom corners of the doors rounded and the rear bumper pieced together like I want it.
I have to get the bottoms of the rear fenders dialed in and make some taillights now. I also did some more sanding on the bottom rolled edge around the entire car and made some trim extensions in my molds out of pieces of sprue melted in liquid cement. The ones I had made out of 5 min. epoxy broke into little pieces.
I also spent a bit of time working on project #2.
My buddy got the doors and trunk cut out and sanded and the interior laid out for his 69 GTX.
Thanks for looking.

Later-

Edited by Modlbldr, 02 March 2013 - 06:22 PM.


#80 Modlbldr

Modlbldr

    MCM Ohana

  • Members
  • PipPipPipPipPipPip
  • 1,821 posts
  • Location:North of Spokane, WA
  • Full Name:Tom Kendall

Posted 17 March 2013 - 08:55 PM

Got a bit more progress made recently and I'll try and post photos tomorrow. I got the side trim glued on and a bit more work done on the bottom of the rear fenders/ bumper area. That area is proving to be a real pain getting it to look like the 1:1. The picture posted on about page two of the rear of the car is going to prove very helpful. After the work I did tonight I looked at that photo and see that I did not get it right. Back to the drawing board.
I did start on the top chop tonight and will try to get progress made on it tomorrow during lunch. The door panels are just about complete and ready for primer. Check back tomorrow evening for progress photos.
