Everything posted by Edward Gore
-
Worked on some interior cab detail. The assembly instruction sheets for the FUG are very thorough and clear but you have to study carefully. (G49) inserts into the slots and over lapse the front edge of (F6). Then the seat assembly is positioned by the front of part (G48) to the front edge of (F6). The seats assemblies are identical until the build gets to parts (G16), the seat adjustment knobs. Insert and glue one of them into the left side of one then into the right side of the other. Once this is done, the commander’s seat and the operator’s seat are established.
- 61 replies
-
- trackmobile
- tractor
-
(and 2 more)
Tagged with:
-
The hole was drilled for the air brake line which will be installed later. Gray primer first for repairs if needed. Yes, it needed 😁 sanding and filling. Then a coat of white to the front. Then vinyl tape masking for the caution lines. This was sprayed with flat black from an aerosol can.
- 61 replies
-
- 2
-
- trackmobile
- tractor
-
(and 2 more)
Tagged with:
-
Went back into the spare parts box to find material to make the front and rear 'Pilot' parts. See reference photo... Then the brackets were made from more parts from the spares box... A template was made then this shape was scribed onto the parts then cut to shape. Then the brackets were shaped to fit around the detail of the traction wheel parts... I'll glue these onto the model after painting.
- 61 replies
-
- 1
-
- trackmobile
- tractor
-
(and 2 more)
Tagged with:
-
1:43 scale peterbilt
Edward Gore replied to 53gmc's topic in WIP: Model Trucks: Big Rigs and Heavy Equipment
Nice finish. What color did you paint it? -
^ (s) = Drive shaft that was shortened to fit this model was found in the spare parts box. (a) = additional length of plastic tube glued to the end of the rear drive shaft part to enable the traction wheel differential to slide forward and rearward. ^ ^ (a) = Inserts into rear traction diff. (t) = Transfer case from the FUG kit. ^
- 61 replies
-
- 1
-
- trackmobile
- tractor
-
(and 2 more)
Tagged with:
-
There isn't very much modern railroad accessories in 1:35 so I have to make the couplers from scratch. The reference photo from the internet shows this unique style coupler. I cut apart another old model tank for the mount and a couple rocket tubes for the knuckles. This photo makes the model look wonky but it's the close up angle of the photo... I think
- 61 replies
-
- 1
-
- trackmobile
- tractor
-
(and 2 more)
Tagged with:
-
Thanks for your compliments. I almost hit a wall with the brass hydraulic cylinders but glad to have managed to solve that with another material.
- 61 replies
-
- trackmobile
- tractor
-
(and 2 more)
Tagged with:
-
Hi @vincen47, Thanks for your compliments. The track section is an injection molded kit in 1:35. This helps me line everything up in 1:35 during the build. The style is WWII era but the "European Gauge" is contemporary gauge for North America.
- 61 replies
-
- trackmobile
- tractor
-
(and 2 more)
Tagged with:
-
Peterbilt 379 RV
Edward Gore replied to vincen47's topic in WIP: Model Trucks: Big Rigs and Heavy Equipment
Thanks for sharing your realistic detail techniques. -
The traction wheels were figured out and installed. The drive traction wheel truck had to slide forward and rearward to contact the rear road wheels to drive on the road. I used the vertical slide rails from the FUG fork lift kit and cut them down to fit this function. The front traction wheel truck is now cemented and curing. They really work!
- 61 replies
-
- 2
-
- trackmobile
- tractor
-
(and 2 more)
Tagged with:
-
I want the arms for the road wheels to articulate so I tried making the hydraulic cylinders from brass but that was a total fail. I need to set up a soldering station for brass fabrication. Until then, I made new ones from the sprue pieces from a couple different kits. Completing these now. Hopefully these will work in plastic.
- 61 replies
-
- 2
-
- trackmobile
- tractor
-
(and 2 more)
Tagged with:
-
Parts G62 and G63 from the Feldumschlaggeät FUG will be used to make the road wheel drive cones. These drive wheels press against the rear road wheel tires to drive them with friction. Grab handle making tool was used to make the grip for the road wheel drive cones. Parts G31 and G32 with G63 for the front traction wheel hubs. Prototype: https://equipmentseller.wf.com/Attachments/Images/original_fe0d807b-b7ae-4b49-b148-8c3394f25b31_998871015_C.jpeg Thanks for looking...
- 61 replies
-
- trackmobile
- tractor
-
(and 2 more)
Tagged with:
-
Working on the traction wheels. I bought two very expensive styrene sheets BUT they included a FREE NEW CAR! 😁 (car dealership ad blanks in the license plate frames). I used this thin sheet material to make discs to cover the outboard side of the traction wheels to look more prototypical.
- 61 replies
-
- 1
-
- trackmobile
- tractor
-
(and 2 more)
Tagged with:
-
'77 GMC Wrecker
Edward Gore replied to bobss396's topic in WIP: Model Trucks: Pickups, Vans, SUVs, Light Commercial
I like where this is going. Looking forward to the colors you chose -
More of the bottom fabrication completed. The holes will receive the axles of the road wheel arms so they can articulate like the 1:1 prototype 🤔 hopefully
- 61 replies
-
- 1
-
- trackmobile
- tractor
-
(and 2 more)
Tagged with:
-
- 61 replies
-
- trackmobile
- tractor
-
(and 2 more)
Tagged with:
-
I hadn't considered that the outside diameter of the road wheels would block view of the pivot point of the road wheel arms at the hub detail. I have to change that so we can see it. I extended them using the wheel axles from the other arms and then glued them together pinning them with brass rod. This will look more interesting on the model.
- 61 replies
-
- 2
-
- trackmobile
- tractor
-
(and 2 more)
Tagged with:
-
@vincen47 and @Ace-Garageguy, Thanks guys for checking in and for your comments.
- 61 replies
-
- trackmobile
- tractor
-
(and 2 more)
Tagged with:
-
Scratchbuilt White 7000
Edward Gore replied to Repstock's topic in WIP: Model Trucks: Big Rigs and Heavy Equipment
Awesome scratch work!
