Found 68 results

  1. Hello All! Following the requests of some fellow members I will start a new threads of some of my completed models starting by the most recent. On this thread I will present my drag version of a ’70 Plymouth Hemi GTX 1/25 scale. I started making plastic models as a youngster in the mid seventies so I just build 1/25 scale and not 1/24 since they were not existing back then. I also want to be able to put my models side by side and don’t want to see any unrealistic proportions between them (I’m kind of purist…). I will go in outline because there are too many details to list and must save my time for my current project (remaining pictures should speak by them self). Using a promo JoHan body, I open-up the hood and trunk with a panel scriber and the back of an Xacto blade. I reproduced all the shapes and reinforcements with various thickness of styrene strips based on pictures found on internet. I also thinned the hood on my milling to make it more realistic. It was roughly 0.080’’ thick without detail since it was molded shut on the promo body. I grafted the underhood section of a newer Revell ’69 Charger Pro Modeler body since it was a perfect match for this project. I also used the floor pan because the JoHan original one was not acceptable for this kind of build. I removed the molded in gas tank and reconstructed the trunk floor with Evergreen styrene sheets. I also tried to recreate all the trunk’s details and embossings of the real car using references found on internet. On the interior, I salvaged the dash of the Charger but I was forced to create all the door panels using styrene (the cup style of the GTX promo was useless and the Charger was too different). I also used thin aluminum sheets to create a drag car interior. I pushed the realism by recreating the instrument cluster gauges with a professional drawing software (Adobe Illustrator). I found pictures of the gauges on internet and used them as template on my computer to exactly recreate them and print in high resolution (2400 DPI) on negative film (pretty crazy…). I also machined all bezels around the gauges, all dash knobs and a radio delete plate (a lot of hours spent in the interior). I machined all the engine components including the block mostly with 6061-T6 aluminum and some brass parts including the oil pan. The Dominator carb itself took me probably 80 hours to build and counts more than 50 parts including the bolts from RB Motion and Scale Hardware. The transmission is a Liberty 4 speed from Futurattraction and I machined a mounting plate for the shifter. I also machined the rear end housing, the Dana 60 cover and a full functional drive shaft including the yokes. I machined my own set of American Racing slot mag wheels with aluminum and they are mounted on wheel hubs with threaded studs and nuts from Scale Hardware. I made all direction components and rods with brass tubes, aluminum rods and RB Motion rod ends. I made the radiator including upper and lower tanks (machined) and photo etch mesh grille (we can see through). Plumbing and wiring as well plus a mirror finish EK2 Go Mango paint job with black accents. Hand made front grille support and machined headlight bezels along with front flashers and rear backup lights bezels. All glasses are made with 0.010’’ clear Evergreen styrene and embedded to the body shell for a more in scale look. Bare Metal done on all body trims including the GTX logo on the side rear fenders. The list can go on and on for hours so take the time to check every pics and judge by yourself… I surprise myself by finding details that I forgot when I look at it after some time on the shelf! I spent around 2000 hours (I’m slower than a turtle…) on a 5 years span working on and off from early 2013 to May 2018 on this build. Unfortunately, I lost most of the construction pictures after a computer crash during an OS update but you should have a good idea with the remaining pics posted. I just taken new pics of the completed model but I really think that they can’t do justice like seen in person. I will be more precautious in the future with frequent backup on USB key as I currently do for the ’64 D100 Pickup I’m building. Dana rear housing in progress Gas tank in milling vise Gas tank final Valve covers unpolished Engine block in progress Engine block front view details Intake in progress Water pump in progress Oil pan installed Spinles and brake calipers Engine exploded view Engine final. The blurry part near the headers is the clutch linkage Engine front details Alternator and brackets closer view. Resin Liberty transmission, aluminum support and aluminum Bellhousing I hand drilled all the holes (around 1000) in the honeycomb pattern promo grille using a 0.018’’ drill bit (I know I’m crazy…). Fuel pump, brass straps for gas tank and hand made housing stoppers Cool can, electric gaz pump, Optima battery and kill switch (you can see some of the trunk floor details) Dash bezels and knobs Cluster gauges installed (I put a flashlight behind to show all the gauges details) Interior in progress Interior with dash and panels in place (hand made Tuff steering wheel) Interior back panel details (all aluminum) Front bumper details including brackets Final view Final view showing mag wheels and wheelie bar Under view front Under view back Front grill details Engine bay final Trunk view final Front bumper closer view
  2. I picked this kit up at an estate sale a while back and decided to put it together. I had plans of doing the car in a dark red exterior with a black interior, however when I put the first layer of primer down I liked the black and decided to go black on black. The plating had come off of one of the bumpers pretty bad, so while deciding what to do with that i was looking at the body partially assembled I thought with a bit of modifications I could make it look just like my 1:1 2018 Dodge Challenger. I went to work removing the things below the front bumper to make it a bit smoother. I left the rear chrome bumper off and added a wired distributor. The rims went through 4-5 modifications will I finally settled on the extra ones that came out of the custom 32 Ford Vicky I recently did (Link). Sorry about the lint in some of the pictures, did not notice till I was editing them for this post and it is raining outside, so taking new ones was not possible.
  3. Hi, everybody just posting a build I've been working on for a while. It's revell's 1/25 hemi cuda, I know some people aren't going to like it and thats okay. But with this kit I wanted to sit low, with wide tire and most importantly keep the rear seat. I've never built one with 4 seats, plus I like flared fenders. This was inspired by a rendering by Andreas Wennevold and the Srt Demon. The engine is the hellcreate demon from Iceman Collections the suspension is revell viper acr. The body still needs to be touch up, and straightened a little but I should get to it within 2 weeks.
  4. Another thread, two nights in a row. Kind of hard to ignore. My build of a '71 Cuda 426. The paint is model master Sublime green. I started and painted this car in January 2018. My first model build with bare metal foil!!! No looking back now. The pictures do not do it justice. The shaker hood scoop needs to be trimmed down. I just painted it and notice it won't let the hood sit flat. What do you think??
  5. Here is a tribute build for my father in law who passed away a few years ago. Lime Green, was his favorite color. And when asked what his favorite muscle car was.... 71' Cuda was his reply. Theses are wheels that I thought looked like a modern version of the stock Mopar wheels. Although, there is a guy named Steve Zimmerman (Steve Z) who makes custom wheels and he has a stock version that are in scale to a 19' front 21" rear, I believe. They look smokin' hot, but in the end, I went with the Mr. Model ones above from Brazil. More to come.... TCB, Adam
  6. Hello All, Philippe, Scott, Luke, Wayne, Anton, Craig, Mark: Many thanks for your kind comments for this build, they are very appreciated and keeps me motivated for my current build!!! Following the good suggestion from an experienced member Dragonhawk1066 I deceided to move this thread in the "Under Glass" category. This make plenty of senses since the car is not WIP but finished. I took a last picture today to create a last post in the hope that it will be linked to the original thread listed in the "Drag Racing Models". I found the hint (I would say) by searching in the "How To Use This Board" so I realy hope it's the right way to do this. In the future I will post all my others completed models in Under Glass (when I'll be ready to do so). Cheers, Francis
  7. Hey, everyone! here is another kit that i had started a few years ago....hopefully posting it will help me get it done! I have as many Muscle car kits as i do exotics, and the 1970 Hemi 'cuda is my favorite one of ALL time! I have a book that my wife, Tina got me, and it had a photo of the one i had to build. Since i already had a super detailed example of a 426 Hemi in my 67 GTX, iwas just gonna build it as a curbside. Since i've gifted away that GTX, i need another example of that engine.......so this will be it. Its gonna be a "modified" curbside, meaning; i'm not concerned about detail of the chassis. The body, engine bay, and interior will all be my usual level of detail. -Photo 2&3; Since MCG wasnt gonna make a detail set for this kit, i got lucky, and found that Hobby Design made!....and boy what a set!!! -it WONT tarnish either! Even though i will use very little of it, its nice to know that its out there for others. The main reasons i got it was for the scripts, and front grills. -Photo 4; This is the kolor it will be, with a white interior, and black trim/ hockey stick stripe. -Photo 5; The stance is set!... -Photo 6&7; heres the starting of the Tub-Job.
  8. I built all of these Challengers, previously posted, in one batch. It allowed me to mix and match parts for the options desired on each. They were all painted in the same week. Having so many at once allowed me to build efficiently and gave freshly glued or painted parts time to dry before being handled again. Their completion resulted in a rainbow of E-bodies.
  9. This model I am very proud of. I absolutely love the Sub-Lime green paint. It says MOPAR, all the way. The rims are from the kit but I used the 5-holers, intended for the rear, on the front. I widened the rear rims by sanding out the centers of a set of ConvoPros and adding them to the original front rims to make them deep dish. I actually had to narrow the rear tires slightly to get them to fit in the quarter panels. What I like the most is I nailed the stance perfectly. The grille was meticulously hand painted and this is the second model I have ever BMF’d. I tried using the black, Hemi “billboard” decals from the kit which are correct for 1971, but I did not like them the minute they were laid. Instead I had Keith Marks make me up a set of 1/24th 1970 “hockey stick” stripes which I think looks a whole lot better. The interior was painted semi-gloss by spraying Testors Glosscoat over Testors flat black. I duplicates the texture and sheen of vinyl. When the head lights were installed, they looked like binoculars. I ended up setting back a tad to get them to look correct. If I ever win the lottery, I would buy a real one.
  10. This model was a difficult endeavor. The body was a resin copy that had a few of resin's typical issues, namely warping and thickness variances. It also was cast without an engine compartment or cowl. I used an AMT Yankee Challenge kit as a donor. With a lot of trimming, most all of the parts fit together. One of the challenges was having no grille or headlight frames. The 1970 parts are way too different to use so, I made them from scratch. The "floating" grille sections turned out so-so, but they do make it look like a 71 at least. The tail lights were drop in with minor trimming. (I think) the fake side scoops were sourced from Drag City Casting. The rear "Go Wing" came from an AMT 71 Duster Kit. The Hemi came from one of my Challenger kits or parts box (it has been a long time). The R/T stripes came from an ebay vendor. Too bad the artwork for the letters was slanted WRONG on the drivers side. (no way to fix it either). I would normally detail paint the rally wheels but after all the other battles, I just wasn't up to it. The first shaker hood I painted and decaled was warped so I tried to fix it with heat. BAD move. I turned it into a potato chip. Fortunately Will, from DPMCC, came to my rescue and sent me a replacement. THANKS WILL!
  11. Never built a Lindberg kit until this one. Screwed up the first paint job on it and hid it in a box for months if not years. Then it became a bit of an experimental subject for scratch built engine parts that didn't make it into the final build. Later, I found a 1972-74 Matchbox Challenger that I absolutely love so I went ahead and replicated it pretty accurately, with some creative freedoms that I took due to the lack of detail on a 1/64 scale Matchbox. Lettering is done by hand, stripes are decals from the '68 Charger kit by Revell. The build itself is pretty far from box stock, with a totally modified front suspension and scratch built rear, carbs and side pipes. Anyways here it is alongside its ''mini-me''. Comments are welcome!
  12. I have not done much over the xmas period, but I did start to fiddle with the MPC Dukes of Hazzard Charger.... I do not plan to build it in Dukes trim, it is a hash up of a few different models; Petty’s ‘73 Nascar charger, amongst others. There is no rear seat, no inner front wings (fenders) apparently the engine is not correct, tires way too fat etc etc so I ‘m going to build my own dream race-prepped street charger mash up. so far I have the 426 cu in hemi painted and built, and I am working on the body at the moment, adding front wheel arch tops as the kit comes with nascar style round-topped arches- I have replaced tbe missing plastic with the bonnet (hood) gap sprue so as to have exactly the same plastic as the front fenders for material integrity. Stock round-topped arch closest to camera, the repaired flat-top at rear: That piece of flat sprue was shaped and welded in place. It even has the correct curvature, so hopefully no stress or strain to crack in the future: Arch is shaped in situ, small gaps are filled with tamiya styrene cement: Righthand arch shaped and primed, lots of wet sanding to do still before the paint goes on, but a seamless repair: Nicely detailed hemi v8, but the manifold headers come with no exhaust pipes to empty into... go figure. I’ll have to make my own from scratch. Other little niggles appear whilst test fitting; such as the roll cage which is designed for the 73 Charger just does not work in this earlier 69 body- more chopping and bending to be done then... All in all not a bad model, but to build it box-stock would be somewhat disappointing for me. There is also a cubic tonne of flash on many parts, everything needs a good clean up, though the detail is more than acceptable. Even the engine block has molded in cylinders and pistons, the heads have the combustion chambers and valves, and even the camshaft and rocker assemblies are supplied. There is a clutch, also never to be seen once assembled.... Obviously some thought was put in to the simple enjoyment of the build, rather than the show of the final result!
  13. I picked up this diecats Hemi Dart a month ago or so. These are selling on EBay for $200+! When one showed up damaged for less than half that, I jumped on it! It has broken attachment points for the base on the underside (which doesn’t bother me) and the hood trim is missing. It’s been sitting on my deathbed since I got it. I figured I would fabricate the missing trim. Here is a little photo selection from the process.
  14. Decided to do a base hood version of the Cuda. Blue Angels Yellow paint. SAM_0355 by Eric Lucas, on Flickr SAM_0360 by Eric Lucas, on Flickr SAM_0367 by Eric Lucas, on Flickr SAM_0368 by Eric Lucas, on Flickr
  15. Its finally finished. My kit bashed, garage sale special, franken-chev is now officially under glass!! Thanks to all the help and support I got on this kit! Please excuse the saturated pictures, my phone not the best.
  16. The newbie here... OK typos aside, this thing is for sure... A 1/16 scale kit. This is my WIP 1957 Chevy Nomad garage sale special. It began its life as a incomplete model, but soon became something that I can tick my Chevy and Chrysler friends off. The simple reason on why I put a 1969 General Lee Hemi in it, is because... why not. The Dodge began its life as a complete model, though after some time it got somewhat destroyed. My hopes are to give the 57 "Ch-emi" the look of a rat rod, on top of the look of an old school street rod. Neat things done: Lowered car, put in a Hemi, roll cage, side exhaust, fuel lines, break lines, ignition wires, and cut out firewall. Neat things to be done: Transmission, electrical wires, finish model.
  17. This is my first stock front suspension car that I’m attempting to build. I’ve had the kit for a while and decided to start on it
  18. Well the magnum is done! I wanted to finish it before the March 19th model meet so I can say I succeeded lol. Pretty straight forward build. Wheels and push bar is from a lindberg charger police car. The hemi billboards are a combo of paint and decals. Custom sub box and audio stuff from my parts box. It went together pretty well, except the headlight lenses suck to install lol. But I'm super happy with the way it came out. Exactly how It looked in my head 😎
  19. I've been working on Revell's awesome new kit for about a month now (I only get a day or two a week to build). All parts are spray painted, it's now time for some detail brush painting, decals, and assembly. I'm hoping to have it done by Thanksgiving. I thought posting here might hold me to that! This is my first build in 3 years, so I'm keeping it close to box stock and fun. I opted to build a Charger 500 by omitting the door scoops and not using any R/T decals. Paint it Testors Hemi Orange and Lacquer Clear. Kit will be box stock except for wheels and tires (plan is to use AMT '70 Chevelle deeper Magnum 500s and L60 tires all around) and maybe a pre-wired distributor. This is a fantastic kit with great proportions, minimal mold lines and beautiful parts fit. I am loving this build, and highly recommend this kit. Thanks for looking, it's good to be back building.
  20. This one has a few little issues to be taken care of (radiator cap, black paint on ends of rear axles where they're exposed, mis-alignment of driver's side interior panel(doh!), but it's pretty much done. The build began in September 2011, and it's progressed in fits and starts since then. Thanks to Acecargarageguy for transmission advice (way back when), and Eric Macleod for trading me a box of old Monogram and MPC tires. They worked out very nicely. A few notes on the build and parts: -Monogram '30 coupe, chopped, wheel wells/bead detail added, Revell '32 5w louvered trunk modified to fit, cowl light and gas filler holes filled. Beltline trim added in half-round styrene and strip plastic. Windows made from overhead projector sheets. -Revell '32 5w interior, brush painted in thin layers of acrylic reds to mimic oxblood leather. Piston shifter and '40 Ford dashboard from same kit. AMT '40 Ford steering wheel. -Floor modified to match width of 1/24 Monogram body. Scratchbuilt trunk floor and interior. -Styrene trunk lid detail and hinges. Gas tank from Lindberg roadster pickup, parts box cap. -Modified Revell '32 frame. Front crossmember moved forward to lengthen wheelbase, Revell '37 Ford PU X-member, Monogram '30 rear crossmember, custom transmission crossmember. Original molded-in floor removed from frame. Friction shocks added from Revell '29 Pickup. -Firewall footwells flattened for engine clearance, scratchbuilt fuel blocks (styrene, hypodermic needle pieces) -Modified Revell '37 Ford axle (dropped, ends filled, posed steering). Scratchbuilt drag link. Pitman arm from Revell '29 Tudor. Metal mono-spring on '29 spring hangars, scratchbuilt radius rods with early style rod-ends. Revell '50 F1 pickup steering box. -AMT phantom Vickie headlight lenses and bezels on modified AMT '40 Ford "Rides" headlight buckets. Headlight stands are cut-down AMT Double-T parts. Taillights are Revell '37 ford with aluminum tube bezels and lenses made by melting red styrene into the bezels with liquid glue. Taillights have 5-min Epoxy on top to give them a domed shape. -Monogram '32 ford roadster '40 Ford-style brake backing plates, plumbed with partial brake lines. -AMT '53 Ford PU Desoto Firedome hemi engine. AMT '57 corvette T-10 transmission with custom JB weld adapter (ha!). Stock exhaust manifolds adapted to side exhaust dumps made from sprue to imitate exhaust pipes made from cut-down '30s Ford torque tubes. Scratchbuilt "U-fab" style intake. Carbs from '53 PU dechromed, split (they're molded in pairs). Parts Box resin intake scoops modified and re-cast, painted with Alclad. Fuel lines are clear stretchy beading wire coated with a red sharpie. Carb linkage made from thin wire crimped on the ends. Scratchbuilt stock-style valley cover and alternator bracket. Scratchbuilt thermostat housing/water hoses between intake and radiator. -aluminum driveshaft with slip joint. Rearend is a quickchange (double dragster?) combined with axle housings from Tweedy pie (I think). -Front tires are Revell '37 Ford PU. Wheels are Revell '32 5w kit's 40-Ford style pieces with AMT '40 Ford "Deluxe" cap on one side only. -Rear tires are MPC '31 Chrysler with modified Monogram '41 Lincoln wheels ('40 ford center lug detail spliced into the Lincoln wheels) -Door handles from Revell '30 Ford touring. License plate from '30 Revell Ford Woody.
  21. My '68 Charger that I just finished. Nice kit, although I had a heck of a time with the front bumper/valance fitting. Had to use super glue on the 3 pieces to get it to stay. Not perfect fit, but I moved on...LOL. I went with the Plymouth Plum Crazy paint and I really liked the way it came out. 3 light coats over the dark gray primer, then 3 light coats of Testor's One Coat clear. I went with the street version mostly, but stuffed the 426 Hemi in there and added some nice Mickey Thompson meats in the rear. Used the Mopar rims and some purple accents on the interior with Purple Embossing powder for the carpet. All in all, I think it came out pretty good. Hope you like it. Once again, much thanks to this board and it's members for the tips, tricks and projects posted. I read through this board a lot!
  22. I bought this kit around 2002. I planned on working on it with my 2 year old daughter. Well, things didn't go as planned and I learned I need patience. So, In the closet it went. Fast forward to October 2016. I pulled it from the closet and gave it a revisit. The more I fiddled with it the more I saw what I wanted to add or subtract. I wanted to do some things I've never done before like cut open the doors and trunk. Since I've never done these things before, this kit taught me quite a bit. The things I can do, the things I can't do and what to do when things go wrong. Lets get started... I knew at the very minimum, I wanted this stance and these Boyd Wheels from the Shezoom kit. I love the look from this view. To get the low rake in the front I flipped over the front spindles so they sit atop the frame rails instead of below. Then I smoothed out the firewall. Then I deleted the emblems on the rear quarter, the hood and trunk. I also removed the door handles although this pic show them. Then I added a new way to open the hood. It was stewing in my head for 3 days before I acted on it. It works pretty well. Also you see the spare HEMI that came with the Charger kit. I cut off the mopar transmission and mounted the GM one in place of it so the motor sits better. I also had to create motor mounts. Next I cut off the doors and trunk. This is where I begin learning. Hinges are tricky and what I finally ended up with, I'm not entirely happy with. I was just tired of working this step over and over and trying every option over and over. I quickly began to realize that I've created multiple weak points because they kept snapping. It occurred to me that I saw a video once on youtube about repairing guitar nuts suing baking soda and super glue. This trick works very well for model kits too. It hardens like concrete. Then I started thinking what if I made the lights functional. At this point I started thinking that I am never going to finish this kit. As you can see, there is plenty of room in the engine bay of a shoebox for a HEMI. Stay Tuned...
  23. well as of today this little hot rod ensemble is done!!!!!!! I need to put a hook on the cable to hold the boat on the trailer but otherwise it's done!!!! 56 build thread the boat build thread Here they are.......
  24. Hey guys, This is the first time I have documented a build so be patient as I work my way through this one. There will be many little steps along the way. The inspiration for this came after seeing the Southeastern Gassers Association's event at Union Dragway in Union SC. I looked over my stash and decided the 41 Plymouth would make a good gasser. The inspiration photo is a 39 Dodge with a 392 Hemi. I love the unpolished, all business approach to this thing and my build will be very similar regarding the final finish. The first order of business was to open the grill. There will be a moon tank between the grill and radiator and I wanted it to be visible through the grill. This was a tedious task that took several sessions with the xacto knife. I will keep the chrome and dull it, and weather the exposed plastic to resemble rust and dirt. Next was the grill shell. It was an ill fitting piece out of the box and required some sanding and gap filling . I may need to revisit this step after primer to make sure everything is smooth. When researching the 1:1 41 Plymouth, the vertical seams can be seen but not the seam running across the front above the grill. The hood was also sanded and filled.
×
×
