Need engine reference photos please.......

[cruz]

Hey guys, anyone of you know where I can get real reference photos for the engine of this model truck or similar? Sites? Links?

[Jim B]

The engine in this kit is a Caterpillar 1160 which is the predecessor to the 3208. I believe Ford designated this a V200 (or something like that). Depending on the year that you are modeling (the kit is a 1973 or so), the engine should be Ford Blue or New Caterpillar Yellow.

This article might help some: http://public.fotki.com/modeltrucks25thscale/model_magazine_articles/car_modeller/cm09_sept_1991_cate/

Here's mine in Ford Blue (same kit, by the way):

A radiator brace was added after this photo was taken.

[cruz]

Thanks my friend!

[Jim B]

Hope it helps.
