Superpeterbilt Posted October 17, 2014 Share Posted October 17, 2014 (edited) So in my spare time at the shop I decided to try to make a better Alcoa rim for the 1/16 trucks. I recently grabbed a few of the Petes and realized that theres virtually no aftermarket in this scale. I strongly dislike the wheels in the kit, so Im doing something about it. I started with some 1.5 Alum round stock and got to it. This is the start of the rough shape before I radiused it with a file.If you notice the shiney line on the outer diameter, thats how far back Im going to bring the radius. After shaping, parting it off, and hogging out the back this is the end of the lathe work. Next, I set my mini rotary table up in the Bridgeport and set up to mill the 20 holes. Next, I made the outer rings. I chose to go with the split rim because Im all about the old school. This will be a master to resin cast. I dont like the kit tires either, so Im going to try a set of tires from the All American Toy Co. Edited February 18, 2015 by Superpeterbilt Quote Link to comment Share on other sites More sharing options...
Superpeterbilt Posted October 17, 2014 Author Share Posted October 17, 2014 P.S. Im also going to be working on some spoke wheels in 1/16. Im turning 2 of my Petes into 353's and they need spokes. Quote Link to comment Share on other sites More sharing options...
Petetrucker07 Posted October 17, 2014 Share Posted October 17, 2014 I miss the days of creating things from a raw chunk of material. These look great Terry. I might just have to build a 1/16 pete if you make these available to public. Quote Link to comment Share on other sites More sharing options...
Superpeterbilt Posted October 17, 2014 Author Share Posted October 17, 2014 I miss the days of creating things from a raw chunk of material. These look great Terry. I might just have to build a 1/16 pete if you make these available to public. Thats what Im shooting for. Im going to make some 5 holes as well. Im going to back date a cab to a little window, and Im planning on casting that as well. Where Im going to find the time, I do not know. Quote Link to comment Share on other sites More sharing options...
Jim B Posted October 17, 2014 Share Posted October 17, 2014 Looks really nice. You're right, there really isn't much in the way of aftermarket parts for thw 1/16 kits. I'd like to swap out the 3408 for a Cummins NTC-series & the long hood on the KW for a standard hood. Quote Link to comment Share on other sites More sharing options...
Superpeterbilt Posted October 17, 2014 Author Share Posted October 17, 2014 Heres two more Quote Link to comment Share on other sites More sharing options...
Casey Posted October 17, 2014 Share Posted October 17, 2014 Quote Link to comment Share on other sites More sharing options...
Superpeterbilt Posted October 17, 2014 Author Share Posted October 17, 2014 Looks really nice. You're right, there really isn't much in the way of aftermarket parts for thw 1/16 kits. I'd like to swap out the 3408 for a Cummins NTC-series & the long hood on the KW for a standard hood. Yes, someone definitely needs to scratchbuild a 1:16 Cummins. Do we have any volunteers? Quote Link to comment Share on other sites More sharing options...
Jim B Posted October 17, 2014 Share Posted October 17, 2014 Not me! I have no talent for that. Quote Link to comment Share on other sites More sharing options...
Superpeterbilt Posted October 17, 2014 Author Share Posted October 17, 2014 It sounds like a job for one if these fellas with a 3D printer Quote Link to comment Share on other sites More sharing options...
Mike77 Posted October 17, 2014 Share Posted October 17, 2014 Great work on those! If I ever do another 1/16 351 I could use some of those spokes when you get them done. Quote Link to comment Share on other sites More sharing options...
Superpeterbilt Posted October 17, 2014 Author Share Posted October 17, 2014 Great work on those! If I ever do another 1/16 351 I could use some of those spokes when you get them done. That is a beautiful truck my friend. Im going to make a 351 myself. Great job Quote Link to comment Share on other sites More sharing options...
lapazleo Posted October 18, 2014 Share Posted October 18, 2014 There was strong after market for thes kits years ago in Australia maybe Auslowe don't remeber but there was an 8v92 detroit spoke wheels roo bars etc Quote Link to comment Share on other sites More sharing options...
Bennyg Posted October 19, 2014 Share Posted October 19, 2014 There was strong after market for thes kits years ago in Australia maybe Auslowe don't remeber but there was an 8v92 detroit spoke wheels roo bars etc Used to be jaymar. He also did a peterbilt 362 cab over, kw s2, kw sar, right and drive dashes,a variety of spoke wheels, cummins, and a 3406 cat. Ben Quote Link to comment Share on other sites More sharing options...
Mike77 Posted October 19, 2014 Share Posted October 19, 2014 (edited) That is a beautiful truck my friend. Im going to make a 351 myself. Great job Thanks! Not to hijack this thread but I made that 1/16 351 ten years ago or so, based on a 1:1. I made this one, and many other 1/16 rigs, about 10 or 12 years ago for a guy on the east coast. I discovered last year that he posted pics of most of them on Flickr claiming that he built them. It's not a good feeling when you put a lot of work into a group of models for someone only to have them tell the world that he did the work. Edited October 19, 2014 by Mike77 Quote Link to comment Share on other sites More sharing options...
Superpeterbilt Posted October 19, 2014 Author Share Posted October 19, 2014 Thanks! Not to hijack this thread but I made that 1/16 351 ten years ago or so, based on a 1:1. I made this one, and many other 1/16 rigs, about 10 or 12 years ago for a guy on the east coast. I discovered last year that he posted pics of most of them on Flickr claiming that he built them. It's not a good feeling when you put a lot of work into a group of models for someone only to have them tell the world that he did the work. Thats sad that same thing has happened to me, just not with models. Ive bad people claim credit for work that Ive done. Ive learned to look at it like this, be flattered, because the best they can achieve is taking credit for what comes easily to you. Quote Link to comment Share on other sites More sharing options...
Petetrucker07 Posted October 19, 2014 Share Posted October 19, 2014 Thanks! Not to hijack this thread but I made that 1/16 351 ten years ago or so, based on a 1:1. I made this one, and many other 1/16 rigs, about 10 or 12 years ago for a guy on the east coast. I discovered last year that he posted pics of most of them on Flickr claiming that he built them. It's not a good feeling when you put a lot of work into a group of models for someone only to have them tell the world that he did the work. I guess thats part of the reason i try not to build for anyone. If i do,, its kinda messed up, but i dont do the job that i would do on 1 if it were gonna be on my shelf. I dont just slap it together sittin crooked or my finger prints on glue all over the windshield. I just dont put the care into it like i normally would, like the revell snap pete i built in 6 hours or the this red freightliner COE that ill be posting pics of once i get the BMF done. Back on topic... I am looking to get a 1/16 pete. The kit rims really are what kept me from wanting 1. I could much more detail and better paint work since its a bigger "canvas", if i can find 1 at a decent i may just get it, and wait for these wheels to be available. Quote Link to comment Share on other sites More sharing options...
Bennyg Posted October 20, 2014 Share Posted October 20, 2014 There was strong after market for thes kits years ago in Australia maybe Auslowe don't remeber but there was an 8v92 detroit spoke wheels roo bars etc Auslowe still does 1/16 right hand drive dashes, aluminium fuel tanks with mounting brackets, and bull/roo bars. Ben Quote Link to comment Share on other sites More sharing options...
Superpeterbilt Posted February 19, 2015 Author Share Posted February 19, 2015 Ive been working on a bunch of other parts to accompany the rims. Tires, brake drums, brake shoes, 6 spoke front and rear wheels, and hubs. The plan is for the hubs to be tapped to recieve scale hardware bolts and acorn nuts. Im also about 80% done backdating a Pete cab to a Unilite little window. I will also be working on a 351 conversion, and walking beam rear suspension. Heres some of the work Ive done. Quote Link to comment Share on other sites More sharing options...
Superpeterbilt Posted February 19, 2015 Author Share Posted February 19, 2015 Quote Link to comment Share on other sites More sharing options...
Superpeterbilt Posted February 19, 2015 Author Share Posted February 19, 2015 Brake drum 90% finished Quote Link to comment Share on other sites More sharing options...
72 Charger Posted February 19, 2015 Share Posted February 19, 2015 Oh my that is nice What do you think the rims and tyres will run at for 10 for a rig? Quote Link to comment Share on other sites More sharing options...
Superpeterbilt Posted February 19, 2015 Author Share Posted February 19, 2015 Oh my that is nice What do you think the rims and tyres will run at for 10 for a rig?Im not that far along yet, but I promise to keep it very reasonable. I dont really do this to make money, I just make this stuff for myself and share it with others. The 1/16 kits are already so expensive, I dont want to add a lot more cost on top of it. As always I will be open to trades for them and things like that. When I get all the parts made and actually start casting, Ill have a better idea what my cost will be. Quote Link to comment Share on other sites More sharing options...
Petetrucker07 Posted February 19, 2015 Share Posted February 19, 2015 Looks like you've been busy after hours. It's nice to have the proper tools available to use. Nice work man. Quote Link to comment Share on other sites More sharing options...
Superpeterbilt Posted February 19, 2015 Author Share Posted February 19, 2015 Looks like you've been busy after hours. It's nice to have the proper tools available to use. Nice work man. Thanks Buddy, as long my CNCs are running, and Im not welding, and Im not QC'ing, and Im not buffing, I can grab a few min on the manual lathe and make this stuff like a 19th century blacksmith. Quote Link to comment Share on other sites More sharing options...
