Hello Everyone! Following the requests of some fellow members I'm starting another thread of one of my completed model. This one is less detailed than the ’70 Plymouth GTX and it will be like that for the subsequent posts since they are older builds (you are the judge so I hope you will be indulgent for the flaws). On this thread you will see my drag version of a 1970 Dodge Dart Swinger 1/25 scale. I don’t recall if I had taken many pictures during the build but I can’t find more than what is posted in this thread. I wanted to build this small Dodge pony car for a long time so I bought a resin kit on internet but I wasn’t satisfied with the rendering so I decided to start my own styrene version with extensive scratch building. I recreated the body by using 3 different kits including the recent Revell ’68 Dart Mr Norm, a used MPC ’70 Dart Ramchargers Funny Car body and the remains of a junk MPC ’71 Dodge Demon. The first operation was to cut the body of the ’68 Dart at the door line, keeping the front fenders and at the base of the back top pillars and between the back window and the trunk lid. I made the inverse operation on the ’70 Ramchargers body keeping the doors and back portion of the body. The Ramchargers front fenders were unusable because the wheel openings were enlarged and at the wrong position, close to the front bumper since it was a Funny Car body. I did cut the front fender extensions on the ’71 Demon body and glued them on the ’68 Dart front fenders. I also used the front grille, valance and hood of the ’71 Demon. A lot of operations but the mock-up picture is self explanatory. I did use the ’68 Dart floor pan as well and add large wheels tubs, recreate the trunk floor in order to add the fuel cell, an electric fuel pump, the battery and a fire extinguisher (all scratch built). The interior has been done using the ’68 Dart door panels, modified to represent a drag racing car. The ’68 Dart dash has been modified to receive the round style cluster like the Dodge Demon and instrument faces made on my computer using Adobe Illustrator and printed on negative film at high resolution (same technique as for the ’70 Plymouth GTX). I spent around 800 hours on a 2 years span working on from mid 2011 to May 2013 on this build. Cheers, Francis

Hello Everyone, After some testing I realized that the frame was too wide between the front wheels so I had to make some adjustments. I cutted the frame and main member to gain more room for the wishbones and get enough space to make sure the front wheels turn freely. I was also forced to modified the main member in order to get enough space for the oil pan. That's the kind of issues that can be encountered when building a model from zero... Scott: I do love this patina look too! Chers, Francis

Hello Mark, I didn't used heat but I first wrap the plastic strip around a way smaller socket overnight to give it the shape I was looking for (to make the styrene more docile I would say). The following day I wrapped the strip around the wanted size socket and held it in place with a rubber band and I glued the flat piece on one side. When both tubs were done I glued them in the bed floor openings and made the final adjustments. Hope this helpful, Francis

Thanks for your kind comments Ray! Still a long way to go but I think it's moving in the right direction. Cheers, Francis

Hello All, Moving back to the structural base of this build I decided to try something new to me by making some of the front suspension components from brass. I do have few experience with welding brass parts and those are critical parts and must be as perfect and equal sized as possible to get the front straight. The brass wishbones will be stronger than plastic and the weld will also make them more reliable than aluminum. The glueing points are too small and the superglue might surrender after some time. Again, I might have to make some adjustment during the construction, it's almost inevitable in this kind of build. Besides, it happens in the real world during the construction of a real vehicle ... Cheers, Francis Part of the front suspension on the milling. This is a part that will receive the bracket for the upper attachment of the shock. Part of the suspension installed on the frame (I inserted aluminum anchors for durability). View of both sides. Wishbone arms in progress made with brass rods and welded by resistance. Closer view Upper and lower wishbones with mounting eyelets. Same pieces, note the perpendicular tiny tubes are the lower shocks mounts.
