As always, a thanks for following along and your interest in the thread.  I do have to acknowledge that today's efforts were challenging thanks to the small factor of the part.  Pete, I completely agree but I do get frustrated at times when I turn my head and then look back and a bunch of super talented builders have completed this, that AND the other thing, while I turn out a little at a time.

Today I started the Enderle fuel pump.  I wanted to capture the 6 ribs on the body of the pump, mine are .4mm x 1.0mm in length.  I drilled holes down through the top and then machined half of it away to expose half of the hole afterwards.  Put the brass rod down through the top and soldered them in place.

Several flanges to make yet, 1 brass, 2  aluminum for the pump body. Then I'll solder the brass bottom flange onto the pump & media blast it for texture like the Cirello mag body.  It will be painted but the aluminum flanges won't.  There are a bunch of little bits and pieces to make up this whole thing, I underestimated how much effort it will take to make I think.  What else is new right?  cheers, tim
